Nondestructive testing and automation systems
Select your language
We design and manufacture systems for ultrasonic testing, geometry measurement and degaussing of rolled metal.
Our quality management system is certified to ISO 9001:2015.
Our equipment meets GOST and API 5L, and the requirements of Shell, ExxonMobil, Gazprom, Transneft and DNV.
“Exporter of the Year”, winner of the “100 Best Goods of Russia” award.
An automated ultrasonic testing system for pipes with diameters of 426–1420 mm has been shipped to the customer. The system is designed for full-coverage (100 %) ultrasonic quality testing of the welded joint, the base metal of the weld-adjacent zone and the pipe ends.
The equipment can test both single-seam and double-seam pipes.
The configuration, systems, number and parameters of the ultrasonic transducers used, the scanning parameters, sensitivity and testing criteria have been selected to fully meet the requirements of the PAO Transneft standards (OTT-23.040.00-KTN-135), API 5L, GOST 31447, GOST 14782, ISO 3183, GOST R 54382 and STO Gazprom 2-4.1-713-2013.
| Parameter | Value |
|---|---|
| Test object | weld seam, base metal of the heat-affected zone (HAZ), base metal of the weld-adjacent zones up to 50 mm wide and base metal of the pipe ends up to 250 mm wide of electric-welded longitudinal single-seam and double-seam steel pipes |
| Pipe outside diameter | 426–1420 mm |
| Wall thickness | 7–25 mm |
| Pipe length | 6–13 m |
| Steel grade (strength category) | low-alloy and carbon steel, austenitic steels |
| Weight of one pipe | 2–25 t |
| Weld seam type | longitudinal, made by automatic submerged arc welding; one or two seams |
On 18 January 2026, the management system certification body "Test-St. Petersburg" decided to recertify ULTRAKRAFT JSC. The company's quality management system has confirmed its compliance with the requirements of the international standard ISO 9001:2015 and the national standard GOST R ISO 9001-2015.
Certificates No. RU.QM075.00114 (ISO 9001:2015) and No. ROSS RU.13SK03.00288 (GOST R ISO 9001-2015) have been issued. Both are valid until 17 January 2029.
Scope of certification: development, design, manufacture, supply, warranty and after-sales service (including the supply of components) of automated systems, instruments and complexes for measuring geometric parameters and for non-destructive testing of products, billets and semi-finished products made of various materials, as well as automation of process lines in metallurgical production.
The quality management system of ULTRAKRAFT JSC has been certified since 2011.
Click an image to open the full-size certificate.
ULTRAKRAFT JSC has carried out pre-shipment tests of an automated ultrasonic testing system for round billets for a forging and pressing complex.
The system is designed for automated non-destructive testing of round forgings made of steel and alloys.
Tell us about your products and inspection conditions, and we will propose a system configuration.
